CZ-15

CX-9NP

High power, instantaneous maximum hoisting force 75 kg (increased by about 30% compared with CX-9 SP)

It is an electric reel of professional specification boasting an instantaneous maximum winding force of 75 kg. Deep sea fishing/big fishing standard reel CX-9SP has further improved power. It can make fine adjustment of the drag with stainless steel slip ring and non grill scratch plate specifications because it is equipped with fishing power control function.

Liquid crystal screen display


Download catalog Download Operation Manual
Target fish (Target fishing)

●Big size Torokinme (red bream)/Beniakoudai (red rock fish) fishing
●Ishinagi (striped jewfish)/Moroko (willow gudgeon)/Kanpachi (greater amber jack) fishing
●Big size Aburabouzu (Skilfish) fishing
●Kimmedai (red bream)/Akodai (red rock fish) fishing around Izu Peninsula/Niijima island/Kozushima island
●Buri (Yellow tail)/Kuromutsu (Black Japanese bluefish)/Umeiro (Yellow tail blue snapper) fishing at the offshore of Cape Ashizuri

Specification
Part numberCX-9NP
Power supplyDC-12VDC-24V
JAN (Japan Article Number) code (last 5 digits)0173201749
Line winding volume
(No.-m)
NEW Deep sensorPE LINE #10-1,600m
PE LINE #12-1,400m
PE LINE #15-900m
PE LINE #20-800m
ナイロン糸PE Line #20:-1,000m
PE LINE #24-800m
PE LINE #30-650m
Maximum load of omission#600
Drag tolerance25kg-47.8kg
Instant maximum hoisting force75kg110kg
Sustained winding up force32kg40kg
Maximum hoisting speed/when without load120M/min.
Manual winding gear ratio1:3.18
Power consumption1.4-23A0.9A-12A
Operating temperature-10℃-80℃
Backlash prevention methodSound brake
Ball bearing11 pieces
Reel self-weight4.8kg
Electronic controlNew hoisting force control
Stop at the bulwarks、Depth memory
Slow start・Slow stop
Stemless speed change(Pause/Minimum speed-Maximum speed)
Safety mechanism+/- Reverse connection prevention、Overload stop control
Battery voltage drop detection、Over-voltage detection
AccessoriesPower cord, Cord for series connection (24V only)
Reel size (W×H×D mm)260×150×220mm
Manufacturer's list price of the bodyYen 267,000.-Yen 275,000.-

* The price indicates the manufacturer's list price only but does not include consumption tax.
* This specification may be changed for improvement without notice.

Explanation of the function icons
